Aung Metals, located in Naypyidaw, Myanmar, has built a solid reputation as a reliable manufacturer and supplier of top-notch metal products, including Aluminium 3003 Bars and Rods. The company stands out for its cutting-edge production methods, rigorous quality control, and dedication to providing materials that align with international standards. The Aluminium 3003 Bars and Rods from Aung Metals are celebrated for their impressive corrosion resistance, excellent formability, and moderate strength, making them perfect for a wide range of industrial uses. Catering to industries like construction, chemical processing, HVAC, food processing, and general engineering, Aung Metals delivers dependable, durable, and high-performance aluminium solutions tailored to meet the unique needs of its customers.
These Aluminium 3003 Bars and Rods are primarily made from an aluminium alloy that includes about 1.2% manganese, which boosts their strength, corrosion resistance, and workability. They showcase mechanical properties such as a tensile strength ranging from 110 to 200 MPa, a yield strength of about 40 to 150 MPa, and an elongation of 10 to 35%, depending on the temper. This alloy is known for its excellent formability, good fatigue resistance, and outstanding performance in both atmospheric and chemical environments. Plus, it’s easy to weld and machine, making it ideal for applications that require durable, lightweight, and corrosion-resistant components.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Grade | Al | Cr | Cu | Fe | Mg | Mn | Other Total | Si | Ti | Zn |
| min. | Remainder | – | 0.05 to 0.20% | 0.7% | – | 1.0 to 1.5% | 0.15% | 0.6% | – | 0.10% |
| Properties | Metric | Imperial |
| Tensile strength | 130 MPa | 18855 psi |
| Yield strength | 125 MPa | 18130 psi |
| Shear strength | 83 MPa | 12039 psi |
| Fatigue strength | 55 MPa | 7977 psi |
| Elastic modulus | 70-80 GPa | 10153-11603 ksi |
| Poisson’s ratio | 0.33 | 0.33 |
| Elongation | 10% | 10% |
| Hardness | 35 | 35 |
| STANDARD | UNS | WERKSTOFF NR. |
| Aluminium 3003 | A93003 | 3.0517 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 3003 bars can be welded using standard welding techniques, such as TIG or MIG welding. Its excellent corrosion resistance and weldability make it ideal for various applications.
Yes, Aluminium 3003 bars and rods are suitable for hygienic and sanitary applications due to their corrosion resistance, lightweight nature, and excellent ability to withstand moisture and chemical exposure.
Aluminium 3003 bars have excellent corrosion resistance due to their manganese content, making them highly resistant to rust and chemical exposure in most environments, including marine and industrial settings.
Aluminium 3003 Bars and Rods find extensive use across various industries, including construction, food and beverage processing, HVAC systems, chemical storage, and general fabrication. They are particularly well-suited for creating heat exchangers, kitchen equipment, fuel tanks, storage tanks, roofing sheets, piping systems, and architectural fittings, thanks to their corrosion resistance and formability. Their lightweight nature and durability also make them a great choice for transportation equipment and sheet metal work. With their versatility and reliability, Aluminium 3003 Bars and Rods have become a go-to option for industries that need long-lasting, easy-to-fabricate, and corrosion-resistant materials.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aung Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Naypyidaw, Myanmar
