Aung Metals is a reputable manufacturer and supplier located in Naypyidaw, Myanmar, specializing in top-notch **Super Duplex Steel Bars and Rods**. Renowned for their precision engineering and unwavering commitment to quality, Aung Metals ensures that their products meet international standards, offering exceptional strength, corrosion resistance, and durability. These Super Duplex Steel Bars and Rods are crafted specifically for tough industrial applications where resistance to pitting, crevice corrosion, and stress corrosion cracking is essential. Catering to sectors like chemical processing, oil and gas, marine, and power generation, Aung Metals provides dependable, long-lasting products that can withstand even the harshest environmental conditions.
Typically, **Super Duplex Steel Bars and Rods** consist of about 24–26% chromium, 6–8% nickel, 3–5% molybdenum, and 0.2–0.3% nitrogen, with the remainder being iron. This unique blend results in a remarkable combination of high mechanical strength and outstanding corrosion resistance. The bars and rods boast a tensile strength ranging from 800 to 1000 MPa, yield strength between 550 and 750 MPa, and an elongation of 25 to 30%. They are particularly resistant to chloride-induced corrosion, showcasing high toughness and excellent performance in both normal and elevated temperatures.
Specifications : ASTM A276, ASME SA276
Standard : ASTM, ASME
Size : 6 mm to 120 mm.
Length : 1 to 6 Meters, Custom Cut Lengths
Dimensions : EN, DIN, JIS, ASTM, BS, ASME, AISI
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32750 | 0.030 max | 1.20 max | 0.80 max | 0.035 max | 0.020 max | 24.00 – 26.00 | 3.00 – 5.00 | 6.00 – 8.00 | 0.24 – 0.32 | 58.095 min |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
| Element | S32760 |
| 0.2% Proof Stress (N/mm2 ) [ksi] minimum | 550 [79.8] |
| Ultimate Tensile Strength (N/mm2) [ksi] minimum | 750 [108.8] |
| Elongation (%) minimum | 25 |
| Reduction of Cross Section Area (%) minimum | 45 |
| Hardness (HBN) | 270max |
| STANDARD | WERKSTOFF NR. | UNS |
| Super Duplex S32750/S32760 | 1.4410 | S32750 / S32760 |
Super Duplex Steel rods are generally resistant to galvanic corrosion due to their high chromium and molybdenum content. However, they can still be susceptible when coupled with highly dissimilar metals in certain environments.
Yes, Super Duplex Steel bars can be welded using appropriate techniques and filler materials. Careful control of heat input and post-weld heat treatment is essential to avoid degradation of their mechanical properties.
Super Duplex Steel rods are available in various sizes, ranging from small diameters to large rods, typically up to 300mm or more. Finishes can include hot-rolled, cold-drawn, polished, or ground, depending on the application requirements.
You’ll find **Super Duplex Steel Bars and Rods** widely utilized in industries that demand high strength and corrosion resistance. They’re perfect for offshore platforms, marine hardware, chemical and petrochemical processing equipment, heat exchangers, and pressure vessels. In the oil and gas sector, they’re employed in pipelines, valves, pumps, and risers that come into contact with seawater or harsh chemicals. Their impressive strength-to-weight ratio and durability also make them ideal for structural components in power generation, desalination systems, and various other industrial applications where reliability and long-term performance are crucial.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
