Aung Metals stands out as a top-notch manufacturer and supplier of high-quality Titanium Grade 3 Bars and Rods, proudly based in Naypyidaw, Myanmar. Known for our precision engineering and commitment to superior material standards, we ensure that our products meet both national and international specifications. Our Titanium Grade 3 Bars and Rods strike the perfect balance between strength, ductility, and corrosion resistance, making them a go-to choice for demanding industrial applications. With a strong focus on quality assurance, timely delivery, and customer satisfaction, Aung Metals is dedicated to serving a variety of sectors, including aerospace, chemical processing, marine, and medical industries, with reliable and high-performance titanium products.
Titanium Grade 3 is primarily composed of titanium (≥99.2%), along with trace amounts of iron (≤0.30%), oxygen (≤0.35%), carbon (≤0.08%), nitrogen (≤0.05%), and hydrogen (≤0.015%). It boasts excellent corrosion resistance and moderate strength among commercially pure titanium grades. Its mechanical properties include a tensile strength of about 450 MPa, yield strength of around 380 MPa, an elongation of 25%, and a density of 4.51 g/cm³. Thanks to its good formability, weldability, and biocompatibility, it’s a fantastic choice for critical engineering and medical applications.
| Standards : | ASTM B348, B863 / ASME SB348, SB863 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr 3 | 3.7055 | R50550 |
| Grade | C | N | O | H | Ti | Fe |
| Titanium Grade 3 | 0..08 max | 0.05 max | 0.35 max | 0.015 max | Bal | 0.30 max |
| Tensile Strength | Reduction of area | Elongation | Hardness |
| 450 | 30 | 18 % | 90 |
| Density | 0.163 lbs/in³ ,(4.51 g/cm³) |
| Mean Coefficient of Thermal Expansion | in/in/°F (mm/m/°C): 70- 212°F (20- 100°C) 4.78 x 10-6(8.6) |
| Thermal Conductivity | BTU-in/h-ft-°F (W/m-°K): At 70°F (21°C): 138 (19.9) |
| Modulus of Elasticity, ksi (MPa) | 15.2 x 10³ (105 x 10³) in tension |
| Melting Point | 3020°F (1660°C) |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Titanium Grade 3 Round Bars Bars Standard lengths of 2000 mm up to 6000 mm. Cut to size on request (tolerance +2/-0 mm).
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
Yes, Titanium Grade 3 has excellent corrosion resistance in aggressive environments like seawater, chemicals, and high-temperature settings, making it ideal for marine and chemical processing industries.
Yes, Titanium Grade 3 has good weldability, making it suitable for various applications where welding is required.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@aungmetals.com
Titanium Grade 3 Bars and Rods find their way into various industries that demand high strength and corrosion resistance. In aerospace, they’re utilized for airframe components and hydraulic systems. The chemical and marine sectors rely on them for heat exchangers, condensers, and seawater piping, thanks to their resistance to oxidizing and mildly reducing environments. In the medical field, they’re essential for surgical instruments and orthopedic implants due to their biocompatibility. Plus, they’re also used in power generation, desalination plants, and industrial equipment where durability, lightweight design, and exceptional corrosion resistance are key.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
