Aung Metals is a reputable manufacturer and supplier located in Naypyidaw, Myanmar, specializing in high-quality **Titanium Grade 11 Forgings** for critical industrial applications. The company has built a solid reputation for its precision engineering, strict adherence to international standards, and unwavering commitment to quality. The Titanium Gr 11 Forgings produced by Aung Metals are known for their strength, ductility, and outstanding corrosion resistance, making them perfect for challenging environments. With cutting-edge manufacturing facilities and expert craftsmanship, Aung Metals caters to various industries, including chemical processing, marine, aerospace, and power generation, providing reliable products that ensure long-lasting performance and durability.
**Titanium Grade 11 Forgings** are primarily made of titanium with a small addition of palladium (0.12–0.25%), which greatly enhances corrosion resistance in reducing and mildly oxidizing environments. This alloy also contains trace elements like oxygen (≤0.18%), iron (≤0.2%), carbon (≤0.08%), and nitrogen (≤0.03%). It boasts a tensile strength of about 345 MPa and a yield strength of around 275 MPa, with an elongation of 24%. These forgings are known for their excellent weldability, toughness, and resistance to crevice and pitting corrosion, even in chloride-rich or acidic conditions.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 11 | 08 max | 03 max | 25 max | 015 max | Bal | 0.30 max | – | 12 – .25 |
| Grade | Tensile Strength min | Yield Strength (0.2 % Offset) | Elongation | Reduction of Area | ||
| ksi | Mpa | ksi | Mpa | min % | min % | |
| 11 | 35 | 240 | 25 | 170 | 24 | 30 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 11 | 3.7225 | R52550 |
Yes, Titanium Gr 11 forgings are highly corrosion-resistant, especially to oxidizing environments and seawater. This makes them ideal for applications in industries like aerospace, marine, and chemical processing, ensuring long-lasting durability.
Titanium Gr 11 forgings are commonly used in industries such as aerospace, marine, chemical processing, medical, and power generation. Their strength, corrosion resistance, and high-performance capabilities make them ideal for demanding applications.
Yes, Titanium Gr 11 forgings can be customized for specific applications, offering tailored sizes, shapes, and properties to meet unique industry requirements, ensuring optimal performance and reliability in demanding environments.
**Titanium Gr 11 Forgings** find extensive use in industries where exceptional corrosion resistance and reliability are crucial. They are commonly used in heat exchangers, marine hardware, pressure vessels, and chemical processing equipment that deal with chlorides, acids, and seawater. The aerospace industry employs them for lightweight structural components, while the power generation and desalination sectors utilize them in condensers and piping systems. Their biocompatibility also makes them ideal for medical applications, such as implants and surgical instruments, ensuring long-term strength, safety, and resilience in harsh operating conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
