Aung Metals is a well-known manufacturer and exporter of stainless steel 316L hex bars with high resistance to sulfuric and phosphoric acids. The resistance to weld deposits of the coated electrodes and bare wire of SS 316L Hexagon Bars/ rods is consistent with that of the base material. Type 316L Metric Hex Bars Available in accurate tolerances, they can be made in a wide variety of sizes, regardless of the quantity required The addition of titanium, combined with the proper heat, increases the stability of Grade 316L hex bars against of inter-granular corrosion induced by corrosion. AISI 316L hex rods exhibit excellent mechanical properties at room temperature up to a certain limit and at higher temperatures. SUS 316L Hex Bars are manufactured to meet the stringent technical standards set by organizations such as ASTM, ASME, BS, SEW, DIN, EN, and ISO. The chromium and molybdenum content of the 316L stainless steel hex bar gives them resistance to chloride-induced pitting and various areas of oxidizing The stainless steel UNS S31603 hex bar exhibits alkali resistance such as hydrofluoric acid, organic acid, sodium or potassium hydroxide, and acid edi chloride synthesis medicines
Stainless Steel 316L Hex Bars/Rods have a composition that typically includes 16-18% chromium, 10-14% nickel, 2-3% molybdenum, and low carbon content (<0.03%), enhancing corrosion resistance and reducing carbide precipitation. They offer excellent mechanical properties, with a tensile strength of approximately 485 MPa, yield strength of 170 MPa, and elongation of 40%. These hex bars/rods maintain mechanical integrity at both room and elevated temperatures, making them suitable for diverse applications. Their combination of strength, corrosion resistance, and durability ensures performance in challenging industrial and environmental conditions.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316l | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 3.00 max | 0.10 max |
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316l | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 3.00 max | 0.10 max |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 316L Hex Bars/Rods offer exceptional resistance to corrosion, including pitting and crevice corrosion caused by chlorides, due to their chromium and molybdenum content. Their low carbon levels prevent sensitization, ensuring durability in marine and chemical environments.
SS 316L Hex Bars/Rods are used in marine, chemical processing, food, pharmaceutical, and oil and gas industries. Their superior corrosion resistance enhances longevity and performance, particularly in environments exposed to chlorides, acids, alkalis, and high-moisture conditions.
Yes, SS 316L Hex Bars/Rods are easily welded and machined due to their low carbon content. However, precautions include using appropriate tools to avoid work hardening, maintaining low heat input during welding, and employing post-weld cleaning to prevent contamination.
Stainless steel 316L hex bars/rods are widely used in various industries due to excellent corrosion resistance, strength and versatility They are commonly used in marine environments for shafts, fasteners and other components, because it resists corrosion by chloride. Used for equipment exposed to strong acids and bases in the chemical industry. The clean and corrosion-resistant properties of these fibers also find applications in the food and beverage industry. In addition, SS 316L Hex Bars are a staple in the chemical, oil and gas industry for structural precision parts.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
