Aung Metals, a reputable manufacturer and supplier located in Naypyidaw, Myanmar, is dedicated to crafting top-notch Nickel Alloy 201 Bars and Rods. These products are celebrated for their outstanding corrosion resistance, strength, and ductility. By employing cutting-edge manufacturing techniques and rigorous quality control measures, Aung Metals guarantees that each Nickel Alloy 201 Bar or Rod adheres to international standards, ensuring dependable performance even in tough industrial settings. Known for their ability to withstand reducing agents, chemical corrosion, and high temperatures, these bars and rods are perfect for industries like chemical, petrochemical, marine, and power generation. Aung Metals delivers precision-engineered nickel alloy solutions that blend durability, toughness, and long-lasting efficiency.
Nickel Alloy 201 Bars and Rods are made up of more than 99% nickel, along with trace amounts of copper, iron, manganese, and carbon. This unique composition grants them exceptional mechanical strength, ductility, and resistance to corrosion in reducing and mildly corrosive environments. In terms of mechanical properties, Nickel Alloy 201 boasts a tensile strength ranging from 450 to 700 MPa, yield strength between 200 and 400 MPa, and an elongation of 40 to 50%. The material also showcases excellent thermal conductivity, fatigue resistance, and workability, making it ideal for high-performance applications in industrial and chemical processing settings.
| Grade | Nickel 201 |
|---|---|
| Specification | UNS N02201, ASME SB160/ASTM B160 |
| Round bar size | Dia: 3mm~800mm |
| Hollow Bar | 32 OD x 16 ID to 250 OD x 200 ID |
| Square bar size | 4mm to 100mm |
| Hex Bar size | 2mm to 100mm A/F |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Billet Size | 1/2″ to 495mm Diameter |
| Channel Bar | 80 x 40 to 150 x 75mm section; 5 to 6mm thickness |
| Flat bar size | Thickness: 2mm to 100mm |
| Width: 10mm to 500mm | |
| Hollow Bar | 32mm Outside Diameter x 16mm Inside Diameter to 250mm Outside Diameter x 200mm Inside Diameter) |
| Angle bar size | 3*20*20~12*100*100 |
| Form | Rings, Hollow, Flat Bar, Rectangle, Triangle, Square,Rod, Half Round Bar, T-Bar, Hex (A/F), Precision Ground Bar, Round, Channel Bar, Blocks, Round Rod, Threaded, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Tolerance | H8, K12, H10, H11, K10, H9, K11, K9, H12, H13, or custom |
| Technique | Forged Round Bar, Rod, Hot Rolled, Cold Drawn, Cold Rolled, |
| Condition | annealed, Hardened and tempered |
| Surface | Polished, Cold Drawn, Hot Rolled Pickled, Sand Blasting Finished, Bright, Hairline |
|
Grade |
Fe |
Si |
C |
S |
Ni |
Mn |
Mg |
Cu |
Ti |
|---|---|---|---|---|---|---|---|---|---|
|
Nickel 201 |
0.4 max |
0.2 max |
0.02 max |
0.01 max |
99.0 min |
0.35 max |
0.15 max |
0.25 max |
0.1 max |
|
Density |
Elongation |
Tensile Strength |
Melting Point |
Yield Strength (0.2%Offset) |
|---|---|---|---|---|
|
8.9 g/cm3 |
45 % |
Psi – 67000 , MPa – 462 |
1446 °C (2635 °F) |
Psi – 21500 , MPa – 148 |
|
STANDARD |
UNS |
WERKSTOFF NR. |
AFNOR |
GOST |
BS |
JIS |
EN |
|---|---|---|---|---|---|---|---|
|
Nickel 201 |
N02201 |
2.4068 |
– |
НП-2 |
NA 12 |
NW 2201 |
NLC-Ni 99 |
Type | SIZES (Inches) | ISO Tolerance | SIZES (mm) |
|---|---|---|---|
Peeled and Polished | 1.50″ to 6.00″ | h11-DIN 1013 | 40.00 to 150.00 |
Cold Drawn and Ground | 5/6″ to 2.50″ | h9-h8-h11-h10 | 10.00 to 75.00 |
Cold Drawn and Polish | 1/8″ to 3.00″ | h9-h8-h11-h10 | 3.00 to 75.00 |
Peeled and Ground | 3/4″ to 2.00″ | h10-h9-h11 | 20.00 to 50.00 |
Cut to size on request (tolerance +2/-0 mm).
50.0 | 6.0 |
45.0 | 5.0 |
60.0 | 8.0 |
55.0 | 7.0 |
70.0 | 10.0 |
65.0 | 9.0 |
75.0 | 12.0 |
90.0 | 20.0 |
80.0 | 16.0 |
100.0 | 25.0 |
160.0 | 35.0 |
130.0 | 30.0 |
200.0 | 40.0 |
Yes, Nickel Alloy 201 rods can be welded using various welding techniques, including TIG and MIG welding.
Nickel Alloy 201 bars exhibit excellent corrosion resistance, high thermal conductivity, good mechanical properties, and outstanding weldability, especially in reducing environments.
Nickel Alloy 201 rods are available in various sizes, typically ranging from 1/8" to 3" in diameter, and come in finishes such as bright, polished, and cold drawn.
These Nickel Alloy 201 Bars and Rods find extensive use in chemical, petrochemical, marine, and industrial applications, thanks to their superior corrosion resistance, strength, and durability. They are commonly utilized in heat exchangers, chemical processing equipment, fasteners, shafts, pumps, valves, and structural components that are exposed to reducing chemicals and moderately corrosive conditions. Additionally, they play a vital role in aerospace, power generation, and offshore platforms where reliability, performance, and longevity are paramount. Nickel Alloy 201 Bars and Rods offer high-performance, precision, and enduring service for demanding industrial and engineering applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
